OROFLEX RELINE
Download Spec SheetExtruded TPU Lay Flat Hose for Pipe Rehabilitation
- Specially designed for drinking water transfer in trenchless pipe network repair. Total corrosion resistance and ease of transportation and handling. Premium flexible leak free hose adaptable to the pipe nominal diameter and fully approved for potable water NSF/ANSI/CAN Standard 61 Certified and BS 6920:2014 Compliant.
- Lengths: Standard lengths in 660ft (200m). Longer lengths may be available upon request.
- Temperature: From -58°F (-50°C) to 150°F (65°C), with peaks of up to 175°F (80°C). Special versions for higher and lower temperatures available upon request.
- Color: Blue cover is the standard. Other colors are available upon request.
| Nominal Pipe Size |
OROFLEX® RELINE Hose Properties | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Inner Diameter | Wall Thickness | Working Pressure | Burst Pressure | Tensile Strength | Nominal Weight | ||||||||
| mm | inch | mm | inch | mm | inch | bar | psi | bar | psi | kg | lb | kg/m | lb/ft | |
| 125 | 5 | F550170A | 92 | 3 1/2 | 3,9 | 0,154 | 17 | 245 | 42 | 600 | 13.000 | 28.600 | 1,45 | 0,97 |
| 150 | 6 | F550171A | 116 | 4 1/2 | 3,9 | 0,154 | 16 | 230 | 35 | 500 | 18.000 | 39.700 | 1,60 | 1,08 |
| 200 | 8 | F550172A | 152 | 6 | 4,5 | 0,177 | 22 | 320 | 55 | 800 | 29.000 | 63.900 | 2,48 | 1,66 |
| 250 | 10 | F550173A | 203 | 8 | 4,3 | 0,169 | 16 | 230 | 42 | 600 | 35.000 | 77.200 | 3,30 | 2,22 |
| 300 | 12 | F550174A | 254 | 10 | 4,5 | 0,177 | 16 | 230 | 35 | 500 | 45.000 | 99.200 | 4,10 | 2,80 |
| 400 | 16 | F550175A | 305 | 12 | 5,0 | 0,197 | 16 | 230 | 35 | 500 | 70.000 | 154.300 | 5,28 | 3,55 |
| 500 | 20 | F550176A | 406 | 16 | 5,2 | 0,205 | 14 | 215 | 28 | 400 | 80.000 | 176.400 | 7,60 | 5,11 |
| Nominal Pipe Size |
OROFLEX® RELINE Hose Properties | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Inner Diameter | External Diameter | ||||||||||||
| at 0,7bar | at 10psi | at 10bar | at 145psi | at 12bar | at 175psi | at 14bar | at 200psi | at 16bar | at 230psi | |||||
| mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | |
| 125 | 5 | F550170A | 92 | 3 1/2 | 100 | 4 | 114 | 4 1/2 | 116 | 4 1/2 | 119 | 4 3/4 | 120 | 4 3/4 |
| 150 | 6 | F550171A | 116 | 4 1/2 | 125 | 5 | 145 | 5 3/4 | 146 | 5 3/4 | 148 | 5 3/4 | 150 | 6,00 |
| 200 | 8 | F550172A | 152 | 6 | 161 | 6 3/8 | 176 | 7 | 178 | 7 | 181 | 7 1/8 | 183 | 7 1/4 |
| 250 | 10 | F550173A | 203 | 8 | 215 | 8 1/2 | 224 | 9 | 226 | 9 | 228 | 9 | 230 | 9,01 |
| 300 | 12 | F550174A | 254 | 10 | 266 | 10 1/2 | 284 | 11 1/4 | 290 | 11 1/2 | 295 | 11 1/2 | 297 | 11 3/4 |
| 400 | 16 | F550175A | 305 | 12 | 315 | 12 1/2 | 345 | 13 1/2 | 352 | 14 | 358 | 14 1/4 | 360 | 14 1/4 |
| 500 | 20 | F550176A | 406 | 16 | 413 | 16 1/4 | 460 | 18 | 475 | 18 5/8 | 479 | 19 | 484 | 19,00 |
